12
CATC F IRE I NSPECTOR 2.01 C HAPTER 2
User’s ManualGetting Started
• Select Start > Programs > CATC > CATC FireInspector from the Windows taskbar.
• In Windows Explorer or My Computer, navigate to the directory that contains
FireInspector, then double-click on the FireInspector.exe icon.
2.2.2 Exiting the Application
Any of the following actions will close the FireInspector application:
• Click on the ‘X’ in the upper right corner of the application window.
• Select File > Exit from the menu bar.
• Press Alt + F4.
• Double-click the FireInspector control icon in the upper left corner of the application
window.
• Click the FireInspector control icon to access the Control menu and choose Close.
2.2.3 Starting the Analyzer Box
Start the FireInspector box by turning the power switch on the back of the unit to the ‘On’
position. The analyzer will initialize itself and perform an exhaustive self-diagnostic test
that lasts about five seconds. The Triggered LED blinks during testing and turns off once the
tests are completed.
2.2.4 Shutting Down the Analyzer Box
Shut down the FireInspector box by turning the power switch on the back of the unit to the
‘Off’ position.
2.3 Displaying Help
The FireInspector application has a help file that is useful as an on-screen reference. Access
the help file by choosing Help > Help Topics... from the menu bar.
2.4 Setting Up the Analyzer
Several utilities for setting up the analyzer unit are available via the Setup menu in the
application.
2.4.1 Resetting the Analyzer
The Reset Analyzer command provides a way to reset the analyzer without turning it off.
It causes the analyzer to reset, perform self-diagnostics, and then return to service. The
self-diagnostics should complete in about 5 seconds, during which time the yellow
Triggered light on the analyzer will be lit. If the diagnostics fail, the light will blink
continually as the analyzer attempts to successfully complete the tests. If this occurs, please
contact CATC, as it may indicate a hardware problem.
