21
CATC F IRE I NSPECTOR 2.01 C HAPTER 3
User’s ManualFireInspector User Interface
Table 3-3: Record Menu Commands
Command Function
Start Starts a recording session
Stop Stops a recording session
Table 3-4: Report Menu Commands*
Command Function
File Information Displays the File Information window, which provides information about the
active file and its recording conditions
Error Summary Displays the Error Summary window, which details the errors in a file
Timing Calculations Opens the Timing and Bus Usage calculator dialog, which is used to set up
calculation of timing and bus usage
Transaction Summary Opens the Specify Packets in Transaction Summary dialog, which is used to set
parameters for generating a Transaction Summary report
Bus Usage Opens the Bus Utilization window, which graphs information about packet length,
data length, and packet speed
*The Report menu is available only when a Trace (.fdb or .txg) file is active in the Display Area.
Table 3-5: Search Menu Commands*
Command Function
Go to Trigger Jumps to the packet immediately preceding the trigger event
Go to Packet/Transaction Opens the Go to Packet/Transaction dialog, which is used to specify a packet or
marker, then jumps to the specified packet
Go to Marker > Packet
(marker) Jumps to the specified marker
Go to > Event type > Event Jumps to the specified event
Find Opens the Find dialog, which is used to set search parameters
Find Next Repeats the previous Find operation
Search Direction
Forward/Backward The current search direction; selecting it reverses the search direction
*The Search menu is available only when a Trace (.fdb or .txg) file is active in the Display Area.
Table 3-6: Tree Menu Commands
Command Function
Retrieve Tree Opens the Tree Retrieving dialog, which is used to reset the 1394 bus and then
collect information to generate a bus topology tree
Read Configuration ROM Opens the Configuration ROM dialog, which is used to read, view and save
Config ROM data
Gather All Vendor Info Collects any available vendor information for devices in an active bus topology
display and shows it in the vendor information blocks of the tree nodes
