Saving and Recalling Waveforms

aveform... in the drop-down menu.

Saving Waveforms

1. In the menu bar, touch

File; then touch Save W

2. In

the

Save Waveform dialog, touch the Save To

button.

3. Touch

inside

the

Source field and select a source from the pop-up menu. The source can be any trace; for

4. Touch

inside

the

Trace Title field if you want to change the default name of your waveforms. Use the

keyboard to type in the new name.

example, a channel (C1-C4), math function (F1-F4), or a waveform stored in memory (M1-M4).

pop-up

Note: You can change the name but not the sequence number.

CAUTION

waveform will be renumbered with the next available number in the sequence.

at the end of the number : "XYZ32a" for example.

• If you are saving to file,

• If you use a name that ends in a number instead of a letter, the instrument may truncate the number. This is

because, by design, the first waveform is automatically numbered 0, the second 1, etc. For example, if you
want to use waveform name "XYZ32" but it is not preceded by waveforms XYZ0 through XYZ31, the

• If you need to use a number in your waveform's name, it is recommended that you append an alpha character

touch the

Data Format field and select a format type from the pop-up menu:

• If you select ASCII or Excel, also touch the SubFormat field and select either Time Data or Time & Ampl.

Then touch the

Delimiter field and select a delimiter character from the pop-up menu: comma, space,

or the

Save file in directory field and browse to the location where you want the

gned automatically and is shown below the field.

semicolon, or tab.

5. Touch

the

Browse button f

file saved. The file name is assi

6. Touch
