• DC Gain Accuracy: ±1.0% of full scale (typical):
±1.5% >/= 10 mV/div
±2.5% 5 mV/div
±3.5% 2 mV/div
• Offset Range:
50 ohms
±100 µV @ 2.0 to 10 mV/div
±200 µV @ 10.1 to 20 mV/div
±500 µV @ 20.1 to 50 mV/div
±1 mV @ 51 mV to 100 mV/div
±2 mV @ 102 to 200 mV/div
±5 mV @ 202 to 500 mV/div
±10 mV @ 502 mV to 1 V/div
±20 mV @ 1.02 to 2 V/div
±50 mV @ 2.02 to 5 V/div
±100 mV @ 5.02 to 10 V/div
1 Mohms
±100 µV @ 2.0 to 10 mV/div
±200 µV @ 10.1 to 20 mV/div
±500 µV @ 20.1 to 50 mV/div
±1 mV @ 51 mV to 100 mV/div
±2 mV @ 102 to 200 mV/div
±5 mV @ 202 to 500 mV/div
±10 mV @ 502 mV to 1 V/div
±20 mV @ 1.02 to 2 V/div
±50 mV @ 2.02 to 5 V/div
±100 mV @ 5.02 to 10 V/div
• Offset Accuracy: Fixed gain setting < 2 V/div: ±(1.5% of offset value + 0.5% of full scale value + 1 mV)
• Variable gain and settings >/= 2 V/div: ±(1.5% of offset value + 1.0% of full scale value + 1 mV)
• Probing System: BNC or ProBus
Horizontal System
• Timebases: Internal timebase common to all input channels; an external clock can be applied at the auxiliary
input
• Time/div Range: Real time: 200 ps/div to 10 s/div, RIS mode: 200 ps/div to 10 ns/div (WR104MXi, WR104Xi,
WR204Xi: 100 ps/div to 10 ns/div), Roll mode: up to 1,000 s/div
• Math & Zoom Traces: 4 math/zoom traces standard
• Clock Accuracy: • Jitter Noise Floor: 2 ps rms typical @ 100 mV/div
• Time Interval Accuracy: Clock Accuracy + Jitter Noise Floor
• Sample Rate & Delay Time Accuracy: equal to Clock Accuracy
