• If you want to change the label's text, touch inside the Label Text field. A pop-up keyboard appears for you to
enter your text. Touch O.K. on the keyboard when you are done. Your edited text will automatically appear in
the label on the waveform.
• To place the label precisely, touch inside the Horizontal Pos. field and enter a horizontal value, using the
pop-up numeric keypad.
• To add another label, touch the Add label button. To delete a label, select the label from the list, then touch
the Remove label button.
• To make the labels visible, touch the View labels checkbox.
To Turn On a Channel Trace Label
Note: If you want to display each trace on its own grid automatically, enable Autogrid by touching Display in
the menu bar, then
Autogrid in the drop-down menu.
On the front panel, press a channel select button, such as , to display the trace label for that input channel
and turn on the channel.
To turn on a math function trace, touch Math in the menu bar, then Math Setup... in the drop-down menu. Touch
the On checkbox for the trace you want to activate.
You can also quickly create traces (and turn on the trace label) for math functions and memory traces, without
leaving the
Vertical Adjust dialog, by touching the icons at the bottom of the Vertical Adjust dialog:
, , , .
Whenever you turn on a channel, math, or memory trace via the menu bar, the dialog at the bottom of the screen
automatically switches to the vertical setup or math setup dialog for that selection. You can configure your traces
from here, including math setups.
The channel number appears in the Vertical Adjust tab of the Vertical Adjust dialog, signifying that all controls
and fields are dedicated to the selected trace.
INSTALLATION
Power-Up
Press the power switch at bottom-left of the front of the oscilloscope to apply or remove power.
Hibernate mode is not supported.
CAUTION
Do not change the System standby and System hibernates settings from their default Never
selections in the Windows® “Power Options” dialog.
