16

WRXi-OM-E Rev C

Trigger & Interpolator Jitter: Channel-to-Channel Deskew Range: ±9 x time/div setting
Interpolator Resolution: 1.2 ps
External Sample Clock (2-channel operation only; Ch 2 only in WaveRunner 62Xi): DC to 600 MHz; 50

ohm (limited BW in 1 Mohm), BNC input, limited to 2 Ch operation (1 Ch in 62Xi), minimum rise time and
amplitude requirements apply at low frequencies.

Threshold

Impedance

(ohms)

Minimum

V

p-p

Minimum Slew Rate

(mV/ns)

TTL 50 3

250

TTL 1

M 3

350

ECL 50 0.2 150

ECL 1

M 0.2 250

0 Cross

50

0.2

150

0 Cross

1 M

0.2

250

Roll Mode: User selectable; available at lower time/div settings

Acquisition System

Single-shot Sample Rate/Ch: 5 GS/s

WaveRunner

44Xi

WaveRunner

64Xi

WaveRunner

62Xi

WaveRunner

104MXi/Xi

WaveRunner

204Xi

All Channels

5 GS/s

5 GS/s

5 GS/s

5 GS/s

5 GS/s

Interleaved

5 GS/s

10 GS/s

10 GS/s

10 GS/s

10 GS/s

2 Channel Max.: 10 GS/s

Maximum Acquisition Points/Ch - 2 Ch/4 Ch

Standard

10M/20M

VL Memory Option

12.5M/25M

Random Interleaved Sampling (RIS): 200 GS/s
Trigger Rate: 1,250,000 waveforms per second

Acquisition Modes

Single-shot: For transient and repetitive signals: 20 ps/div to 1000 s/div
Sequence: 1000 segments standard
Sequence Time Stamp Resolution: 1 ns
Intersegment Time: 800 ns

Acquisition Processing

Time Resolution (minimum, single-shot): 200 ps (5 GS/s); 100 ps (10 GS/s)
Averaging: Summed averaging to 1 million sweeps; Continuous averaging to 1 million sweeps
Enhanced Resolution (ERES): from 8.5 to 11 bits vertical resolution
Envelope (Extrema): Envelope, floor, roof for up to 1 million sweeps
