In Dual Parameter Compare mode, your X-Stream oscilloscope gives you the option to compare to each other
parameter results measured on two different waveforms. You can set your test to be true if Any waveform or A
waveforms fit the criterion st

ipulated by the comparison condition. Your setup is conveniently shown in the

Summary box of the

Qx dialog. For example:

Mask Tests

You have the choice to do mask testing by using an existing mask, or by using a mask created from your actual
waveform, with vertical and horizontal tolerances that you define. Existing masks can be loaded from a floppy
disk or from a network.

You can set your mask test to be True for waveforms All In, All Out, Any In, or Any Out. For example, if you sele
All In, the test will be False if even a single waveform falls out

side the mask.

Masks that you create from your wavef

f the trace by use of a measure

gate. (See M

an explanation of how

feature works.)

the

Stop Test checkbox in

ctions dialog, you can set up the test to end after a predetermined

weeps that you decide.

orm can be confined to just a portion o

easure Gate for

this

Actions

By touching

the

number of s

You can also decide the actions to occur upon your waveforms' passing or failing, by selecting one or all of the

• save waveform

following:
• stop

• audible alarm

• print image of display

• emit pulse

The selection

Pulse

causes a pulse to be output through the Aux Out connector at the front of the

oscilloscope. This pulse can be used to trigger another oscilloscope. You can set the amplitude and width of th
pulse as described in Auxiliar

y Output Signals.

Depending on your oscilloscope model, you can configure up to 8 pass/fail conditions. The Boolean conditions t
determine if your waveform passes are as follows:

All True

All False

Any True

Any False

All Q1 to Q4

Or All Q5 to Q8

Any Q1 to Q4

And Any Q5 to Q8
