Measure Tools (standard)

Display any 8 parameters together with statistics, including their average, high, low, and standard deviations.
Histicons provide a fast, dynamic view of parameters and wave shape characteristics.

• amplitude
• area
• base
• cycles
• delay
• delta

delay

• delta time @ level
• Dtrig

time

• duration
• duty

cycle

• fall time (90-10%, 80-20%, @ level)
• first
• frequency
• last
• level @ x
• MATLAB

param

• maximum

• mean
• median
• minimum

• number of points
• overshoot+
• overshoot-
• peak-to-peak
• period
• phase
• rise time (10-90%, 20-80%, @ level)
• rms
• std.

deviation

• time @ level
• top
• width
• width

negative

• x @ minimum
• x @ maximum

Pass/Fail Testing

Test multiple parameters against selectable parameter limits at the same time. Pass or fail conditions can initiate
actions including: document to local or networked files, email the image of the failure, save waveforms, send a
pulse out at the front panel auxiliary BNC output, or (with GPIB option) send a GPIB SRQ.

General

Auto Calibration: Ensures specified DC and timing accuracy is maintained for 1 year minimum.
Power Requirements: Single phase, 100 to 240 V

rms

(±10%) at 50/60 Hz (±5%); or single phase, 100 to 120

V

rms

(±10%) at 400 Hz (±5%); Automatic AC voltage selection

Voltage Range:

90 to 264 V

rms

90 to 132 V

rms

Frequency Range:

47 to 63 Hz

380 to 420 Hz
