• Bandwidth @ 1 Mohms (-3 dB) - typical:
WaveRunner 44Xi
10 mV/div to 10 V/div
400 MHz
WaveRunner 64Xi
10 mV/div to 10 V/div
500 MHz
WaveRunner 62Xi
10 mV/div to 10 V/div
500 MHz
WaveRunner 104MXi and
WaveRunner 104Xi
5 mV/div to 10 V/div
2 mV/div to 4.95 mV/div
500 MHz
350 MHz
WaveRunner 204Xi
5 mV/div to 10 V/div
2 mV/div to 4.95 mV/div
500 MHz
350 MHz
• Input Channels: 4 (model 62Xi: 2)
• Calculated Rise Time: 10 mV/div to 1 V/div, 50 ohms (input risetime >/= 50 ps):
WaveRunner 44Xi
875 ns
WaveRunner 64Xi
625 ps
WaveRunner 62Xi
625 ps
WaveRunner 104MXi and
WaveRunner 104Xi
400 ps
WaveRunner 204Xi
225 ps
• Bandwidth Limiters:
o
Full
o
200
MHz
o
20
MHz
• Input Capacitance, using PP008 probe: < 9.5 pF (typical)
• Input Capacitance of Channel (1/1, 1/10, 1/100): < 20 pF (typical)
• Input Impedance: 1 Mohms // 16 pF or 50 ohms; WR104MXi, WR104Xi, WR204Xi: 1 Mohms // 20 pF or 50
ohms
• Input Coupling: 50 ohms: DC, GND; 1 Mohms: AC, DC, GND
•
Max Input Voltage (1/1, 1/10): 50 ohms: 5 V
rms
; 1 microsecond pulse, 50% duty cycle: ±10 V
peak
1 Mohms: 400 V max. (peak AC: = 5 kHz + DC) WR104MXi, WR104Xi, WR204Xi: 50 ohms: 5 Vrms; 1
Mohms: 250 V max. (DC + Peak AC = 10 kHz)
• Installation (Overvoltage) Category: CAT I
• Channel-to-Channel Isolation: > 40 dB @ < 100 MHz (> 30 dB @ full bandwidth)
• Vertical Resolution: 8 bits; up to 11 bits with enhanced resolution (ERES)
• Sensitivity: 50 ohms: 2 mV to 1 V/div fully variable; 1 Mohms: 2 mV to 10 V/div fully variable
