IAI America PCON-SE User Manual
Page 66
54
4. Description of Operating Functions
(Controller
→ PLC)
Register
Bit
address
Bit
position
Signal
symbol
Signal name
Description
15 – 9
⎯
⎯
⎯
0147H
8
PZONE Position zone output
This signal becomes “1” when the current
position is within the setting range if
individual zone boundaries are set in the
position table.
Zone status
register
ZONS
Address
9013H
7 – 2
⎯
⎯
⎯
014EH
1
ZONE2 Zone output 2
This signal becomes “1” when the position
is within the setting range of the parameter
zone boundary 2.
[Common]*
014FH
0
ZONE1 Zone output 1
This signal becomes “1” when the position
is within the setting range of the parameter
zone boundary 1.
15 – 6
⎯
⎯
⎯
013AH 5 PM32
013BH 4 PM16
013CH 3 PM8
Position no.
status
register
POSS
Address
9014H
013DH 2 PM4
013EH 1 PM2
[POS
specification]* 013FH 0 PM1
The position complete position no. is
output as a 6-bit binary code.
(Controller
→ PLC)
Register Address
Description
9000H
b15
b8
b7
b0
High
order
Sign
PNOW
Current
position
9001H
Low
order
*
[Numeric
specification]
The current position is indicated as a 32-bit signed integer (unit: 0.01 mm).
If a negative value is set, it is displayed as a 2’s complement. Accordingly, the
most significant bit becomes “1.”
