143

* Appendix

Appendix

Parameter Record

Recorded date:

Types: a: Parameter relating to actuator stroke range

b: Parameter relating to actuator operating characteristics
c: Parameter relating to external interface
d: Servo gain adjustment

No.

Type

Symbol Name

Unit

Data

1

a

ZONM Zone limit 1 + side

mm

2

a

ZONL

Zone limit 1 – side

mm

3

a

LIMM

Soft limit + side

mm

4

a

LIML

Soft limit – side

mm

5

a

ORG

Home direction [0: Reverse / 1: Forward]

-

6

b

PSWT Push-motion completion judgment time

msec

7

d

PLG0

Servo gain number

-

8 b VCMD

Default

speed

mm/sec

9 b ACMD

Default

acceleration/deceleration

G

10 b INP Default

positioning

band (in-position)

mm

12

b

SPOW Current-limiting value at standstill after positioning

%

13

b

ODPW Current-limiting value during homing

%

16

c

BRSL

SIO communication speed

bps

17

c

RTIM

Minimum delay time for slave transmitter activation

msec

18

b

LS

Home sensor input polarity

-

22 a OFST

Home

offset

mm

23

a

ZNM2

Zone limit 2 + side

mm

24

a

ZNL2

Zone limit 2 – side

mm

28 b PHSP1

Default direction of excited phase signal detection [0:
Reverse / 1: Forward]

29

b

PHSP2 Excited phase signal detection time

msec

31

d

VLPG

Speed loop proportional gain

-

32

d

VLPT

Speed loop integral gain

-

33

d

TRQF

Torque filter time constant

-

34 b PSHV

Push

speed

mm/sec

35 b SAFV

Safety

speed

mm/sec

39 c FPIO1

Positioning complete signal output mode [0: PEND /
1: INP]

-

42

b

FPIO4 Enable function [0: Enable / 1: Disable]

-

43

b

AIOF

Home check sensor input polarity

-

45

c

SIVM

Silent interval multiplication factor

times

46 b OVRD

Speed

override

%

53

b

CTLF

Default standstill mode

-

77

b

LEAD

Ball screw lead

mm

78 b ATYP

Axis

operation

type

-

79

b

ATYP

Rotational axis mode selection

-

80

b

ATYP

Shortcut selection for rotational axis

-

83

b

ETYP

Absolute unit [0: Do not use / 1: Use]

-
