130
* Appendix
Appendix
Correlation diagram of speed and loading capacity for the dustproof/splash-proof
type
(Note) In the above graphs, the number after the type code indicates the lead.
(Note 1) The figures for horizontal installation assume use of an external guide.
(Note 2) Use of the actuator at the maximum loading capacity corresponding to the applicable speed may cause vibration/overshooting.
Select an appropriate model that provides an allowance of approx. 70%.
Horizontal installation (Note 1) Vertical installation (Note 2)
High
-spee
d type
Medium
-spee
d type
Low-speed type
Speed (mm/sec)
Loa
d ca
p
a
city
(kg)
Speed (mm/sec)
Loa
d ca
p
a
city
(kg)
Speed (mm/sec)
Loa
d ca
p
a
city
(kg)
Speed (mm/sec)
Loa
d ca
p
a
city
(
k
g)
Speed (mm/sec)
Loa
d ca
p
a
city
(
k
g)
Speed (mm/sec)
Loa
d ca
p
a
city
(kg)
