Code Message name Cause/Action
20C CSTR-ON during
operation
This message indicates that the start signal (CSTR) became “1” by the PLC
while the actuator was moving, and that duplicate movement commands
occurred as a result.
20E Soft limit over This message indicates that a soft limit was reached.
210 HOME-ON during
operation
This message indicates that the home return signal (HOME) became “1” by
the PLC while the actuator was moving, and that duplicate movement
commands occurred as a result.
221 Write in monitor mode
prohibited
This message indicates that position table or parameter writing operation was
performed in the monitor mode.
223 Operation in monitor
mode prohibited
This message indicates that actuator movement operation was performed in
the monitor mode.
301
302
304
305
306
308
30A
30B
Overrun error (M)
Framing error (M)
SCIR-QUE OV (M)
SCIS-QUE OV (M)
R-BF OV
Response timeout (M)
Packet R-QUE OV
Packet S-QUE OV These messages indicate an error in the serial communication with the
controller.
Cause: [1] Garbage data due to the effect of noise
[2] Duplicate slave numbers when multiple controllers are controlled
by serial communication.
Action: [1] Adjust the wiring in a manner eliminating the effect of noise and
review the installation of equipment, etc.
[2] Change the slave numbers to avoid duplication.
If the message is still displayed after taking the above actions, please contact
IAI.
307 Memory command
refused
This message indicates that the command was refused in the serial
communication with the controller.
309 Write address error This message indicates that an indeterminate WRITE address error occurred
in the serial communication with the controller.
These conditions do not occur in normal operation. Should they occur, record
the entire error list before cutting off the power for use in the cause
investigation.
Also contact IAI.
30C No connected axis This message indicates that no controller axis number is recognized.
Cause: [1] The controller is not operating properly.
[2] Only the supplied communication cable (SGA/SGB) is
disconnected.
[3] If a SIO converter is used, 24V is supplied to the converter but the
link cable is not connected.
[4] When multiple controllers are linked together, the same number is
set by mistake on two or more ADRS switches.
Action: [1] Check if the RDY lamp on the controller is lit. If the lamp is not lit,
the controller is faulty.
[2] If a spare teaching pendant is available, replace the current
pendant with the spare unit, or with a PC, and see if the message
disappears.
[3] Supply power after connecting the link cable between the
converter and controller.
[4] Make sure there are no duplicate ADRS switch settings.
If the message is still displayed after taking the above actions, please contact
IAI.
