Potentialfree binary input as "Flow Switch"
logical value input voltage
Input signal:
Not inverted (Inv = No) Input signal:
Inverted (Inv = Yes)
Open contact (*) 0 / Ok 1 / No Flow
0 … 4.5 V (*)
13 … 35 V (*) 1 / No Flow 0 / Ok
(*) The input voltage has to be applied continuously in the according range longer than the parameterized
delay time, before the logical value is accepted or changes.
Frequency- or 4-20mA-input as “Flow Switch”
input value logical value
< SP No Flow (**) 1 / No Flow
>= SP No Flow (**) 0 / OK
(**) The input value has to be available according to the requirement (< or >=) longer than the parameterized
delay time, before the logical value is accepted or changes.
Configuration
Configuration
Flow Switch Access
via Cfg.-
menu Access
via XML-
Cfg.-File Abbre-
viation
(menu)) Value range Default values
(after factory reset or at
start of Cfg-File-
Download)
"Flow Switch" function
Enable/Disable rw rw Flow
Switch
On/Off Off
Set point (*) No Flow rw rw SP -99999 … 99999
(in the unit of
assigned input) 0.0
Delay time rw rw Delay 0 … 1800 s 1.0 s
Input r rw Input DigIn 1, DigIn 2,
DigIn 3, DigIn 4,
No Input No Input
(*) will be only displayed if a 4-20mA or frequency input is selected as „Flow switch“ input
