mxCONTROL Type 8620
Page 107
Maximum Output Timer (MOT)
Compare the description of the Maximum Output Timer in section "Maximum Output Timer (MOT)" in
chapter 14.3.2.
Total Dissolved Solids (TDS)-Display
The TDS display is only available for the conductivity process value of the System Channel.
Please refer to the description on section "Total Dissolved Solids (TDS)-Display" in chapter 14.3.1
Processdata and Data Logging
Display-Presentation Displayed data Abbre-
viation
(menu)
Full
Screen
Trend
chart
Line
Data-
Log.
Notes
Process value System Channel PV1 x x x x
Process value System Channel
(in ppm) PV1 x x x Only if TDS-Display
is configured
Process value Make-Up
Channel PV2 x x x x
Set point SP x x x
Set point vs. Process value
System Channel SP/PV1 x
Module output CMD x x x
Alarm Maximum Output Timer x x is displayed only if
MOT was enabled
and is expired;
Data log in controller
output
Parameter (CodeLevel: Operator)
Parameter Abbreviation
(menu) Value range Default values
(after successful download of Cfg-
File)
Sample Time Tsample 0.05/0.1 … 60.0 s 0.2 s
For Make-Up Channel:
Ratio
Kx 1.2 … 9.9 2.0
Offset Offset 0 … 999.9 µS/cm 10 µS/cm
For System Channel:
Gain/amplification factor
Kp 0.001 … 9999.0
(in % / unit) 10.0
Reset time Tn 0.1 ... 9999.0 s 9999.0 s
Lower output limit Lim- 0.0 % ... Lim+ 0.0 %
Upper output limit Lim+ Lim- ... 100.00 % 100.00 %
Safety output value CMDsafe 0.0 ... 100.00 % 0.0 %
Maximum output timer (MOT)
Maximum output time (*)
+Tm 1 ... 10800 s 10800 s
For TDS-Calibration:
Conductivity value (**)
PV cal 1 ... 99999 (in units of the
assigned process value
input) 1000
TDS value (**) TDS cal 1 ... 99999 ppm 800 ppm
(*) will be only displayed if the parameter “MOT” is configured as “Yes” in the menu „Configuration“
(**) will be only displayed if the parameter “TDS Disp” is configured as “Yes” in the menu „Configuration“
