Low Pass Filter
Please refer to the description of the low pass filter in section 12.2.1.
(Process Value) Alarm
Please refer to the description on the process value alarm in section 12.2.1.
Configuration (CodeLevel: Specialist)
Configuration Access
via Cfg.-
menu Access via
XML-Cfg.-
File Abbre-
viation
(menu) Value range Default values
(after factory reset or
at start of Cfg-File-
Download)
Enabling / disabling
input rw rw Input On/Off Off
Process value
scaling: unit rw rw Scal Unit °C, °F, °Rank, K °C
Process value
scaling:
low scaling value rw rw Scal- -200 ... Scal+ (in selected
unit)
-200
Process value
scaling:
high scaling value rw rw Scal+ Scal- ... 800 (in selected
unit) +800
Correction Value rw rw CorVal Depending on the selected
unit:
-20.0 ... + 20.0 °C or K -
36.0 ... + 36.0 °F or °R 0.0 °C
Filter stage rw rw Filter 0 ... 9 0
Process value alarm
Alarm mode
rw rw Mode Off, Alarm,
Alarm & Warn Alarm & Warn
Low alarm limit (*) rw rw Alarm- -99999 … Alarm+ -99999
High alarm limit (*) rw rw Alarm+ Alarm- … 99999 99999
Alarm hysteresis (*) rw rw AlarmHys 0.1 … 10.0 % of range
(Scal- … Scal+) 1.0 %
Low warning limit (*) rw rw Warn- Alarm- … Warn+ -99999
High warning limit (*) rw rw Warn+ Warn- … Alarm+ 99999
Warning hysteresis (*) rw rw WarnHys 0.1 … 10.0 % of range
(Scal- … Scal+) 1.0 %
(*) will be only displayed if the corresponding Alarm Mode is selected
