mxCONTROL Type 8620
Page 172
21.5.5 System Settings
- Current Firmware ID-No. and Revision
- Current Eeprom Revision
- Number of cold device starts (power off)
- Number of warm device restarts (via Restart Device or due to
internal fault)
The number of cold and warm starts can be reset independently
from each other. The Master Code is required for resetting.
- Restart Device:
Press START-Softkey continuously for 4 seconds to
restart the device.
Before the restart is done, the Specialist Code has to be
entered correctly.
During restarting the outputs will be set to
power-off-state!
( ** )
!
Processdata
BW 06T
Parameter
Configuration
System settings
ENTER 4
EXIT
from Item
5
to Item
5
to Item
4-5
from Item
4-5
from Item
4-1
to Item
4-1
EXIT
ENTER
EXIT
EXIT
... ...
Use the Arrow-Up-/Down-Softkeys
for scrolling through the list.
Device Information
- Device Ident-No.
- Serial Number
- Hardware information
- Hardware Options
EXIT
to Item
3
from Item
3
Language
System settings
EXIT ENTER 4-1
... ...
Use the Arrow-Up-/
Down-Softkeys for
scrolling through the list.
... ...
Use the Arrow-Up-/
Down-Softkeys for
scrolling through the list.
System settings
EXIT INPUT 4-3
System settings
EXIT ENTER 4-4
Language Settings
Display Settings
for display inversion and
display brightness (10 steps)
Factory-Reset
Press INPUT-Softkey continuously for 4 seconds to
reset the whole device to factory settings.
Before the factory reset is done, the Specialist Code has to be
entered correctly.
( ** )
EXIT
EXIT
Ident-No. 00188136
Device Info
Serial-No. 00001000
Hardware
EXIT 4-4-1
Ident-No. 00188136
Device Info
Serial-No. 00001000
Hardware
EXIT ENTER 4-4-3
Device Info
Cold start 20
Warm start 3
Restart Device
EXIT START 4-4-C
... ...
Use the Arrow-Up-/Down-Softkeys
for scrolling through the list.
ENTER
EXIT
Hardware
EXIT 4-4-3-2
Hardware information
(display only)
- PCB MCU and I/O
(Ident-No. and Index)
- Details
(for service only)
!
!
ENTER
Code-Protection:
Specialist-Level (**)
Revision C.00.00.00
Device Info
Ident-No. 00797645
---- Firmware -----
Eeprom C.00
EXIT 4-4-8
-------------------
EXIT
... ...
Display
Factory Reset
Device Info
ENTER
EXIT
Language
EXIT SELEC 4-1-2
German
English
French
===================
ENTER
EXIT
Display
EXIT SELEC 4-2-1
normal
inverse
Brightness 5
Language
System settings
EXIT ENTER 4-2
Display
Factory Reset
Device Info
===================
Language
Display
Factory Reset
Device Info
Display
Factory Reset
Device Info
Network Info Hardware Options
Hardware Options
... ...
Use the Arrow-Up-/Down-Softkeys
for scrolling through the list.
EXIT
Ident-No. 00188136
Device Info
Serial-No. 00001000
Hardware
EXIT ENTER 4-4-4
ENTER
EXIT
Transistor-Outputs
Hardware Options
4-20mA Outputs
Ethernet
EXIT 4-4-4-1
Hardware Options
- display only
Hardware Options
Ident-No. 00797178
Index D
----- PCB I/O ------
----- PCB MCU ------
Ensure to save the current configuration and parameterisation
to SD-Card or PC before applying a factory reset to the device!
After applying a factory reset the (new) device configuration
and parameterisation has to be downloaded again !
Menu item 4-5 Network info is
only visible for devices with
enabled
Ethernet Option.
