mxCONTROL Type 8620
Page 22
6.4 Module Overview
This table shows the available standard modules which can be combined specifically for the
application. They can function either as process or control or merely as display module.
The module names as used in the configuration files and the short designations for the menu are
listed as well as a short explanation of the module type.
Module-name for XML-
configuration-file Short name in
menu Module type
NONE -- --
BATCH Batch Batch-Dosing
BIOCIDE_DOSING BioDos Biocide-Dosing
CL_ORP CL/ORP Chlorine/Redox-PI-Control
COMMON_PID PID General PID controller
COND_CONTROL Cd Conductivity On/Off control
COND_CONTROL_RATIO Cd r Conductivity On/Off control, set point via ratio from Make-Up
Channel
COND_PI Cd-PI Conductivity PI-Control
COND_PI_RATIO Cd-PIr Conductivity PI-Control,
set point via ratio from Make-Up-Channel
CORROSION_DISPLAY CorroD Corrosion-Display
MONITOR_PV Mon PV Monitoring only up to two process values (data logging) and
optionally output
O2_SCAV_CTRL_RATIO O2SCR Dosing of oxygen absorption media based on flow rate and
temperature of the feed water
OPEN_PROP OpProp Dosing (proportionally to process value)
PH_ACID_CAUS pH-AC pH PI-Control with outputs for acid and caustic pumps
PH_ ACID_OR_CAUS pH-A/C pH PI-Control with output for acid (or caustic) pump
TOTALIZER Total 2-channel totalizer
Table 3: Module designations and types
