Configuration (CodeLevel: Specialist)
Configuration Access
via
Cfg.-
menu Access
via XML-
Cfg.-File Abbre-
viation
(menu) Value range Default values
(after factory reset or
at start of Cfg-File-
Download)
Enabling / disabling
input rw rw Input On/Off Off
USE_KFACTOR -- rw -- 0; 1 0
Unit K-Factor *) rw rw K-Factor
Unit (Pulses per) …
L, m³, Gal US, bbl US,
gal Imp, ft3, Pulse Pulses per L
K-Factor *) rw rw K-Factor 0.001 ... 9999.0 1.0
Frequency range:
Lower value**) rw rw Freq- 0 Hz … Freq+ 0.0
Frequency range:
Upper value**) rw rw Freq+ Freq- … 2000 Hz 2000.0
Process value scaling:
unit rw rw Scal Unit Units of Chem.
Analysis, Volume, Flow,
Temperature, Misc; if *)
then only Flow***) No Unit
Process value scaling:
low scaling value rw rw Scal- -99999 … Scal+ -99999
Process value scaling:
high scaling value rw rw Scal+ Scal- … 99999 99999
Process value
scaling**): Sense of
action rw rw ScalDir Rise / Fall Rise
Filter stage rw rw Filter 0 ... 9 0
Process value alarm
Alarm mode
rw rw Mode Off, Alarm,
Alarm & Warn Alarm & Warn
Low alarm limit (****) rw rw Alarm- -99999 … Alarm+ -99999
High alarm limit (****) rw rw Alarm+ Alarm- … 99999 99999
Alarm hysteresis (****) rw rw AlarmHys 0.1 … 10.0 % of range
(Scal- … Scal+) 1.0 %
Low warning limit (****) rw rw Warn- Alarm- … Warn+ -99999
High warning limit (****) rw rw Warn+ Warn- … Alarm+ 99999
Warning hysteresis
(****) rw rw WarnHys 0.1 … 10.0 % of range
(Scal- … Scal+) 1.0 %
*) only visible if "Use K-Factor for Scaling" = 1
**) only visible if "Use K-Factor for Scaling" = 0
***) the units “P/m”, “P/s” are only accepted, if the unit pulses per “Pulse” is selected at “Unit K-Factor”;
other units are only accepted, if not the unit pulses per “Pulse” is selected at “Unit K-Factor”
(****) will be only displayed if the corresponding Alarm Mode is selected
