mxCONTROL Type 8620
Page 46
11.5 Communication
11.5.1 USB
Device access via USB allows putting the “Type 8620 mxCONTROL” easily into service.
This functionality is available from Firmware Rev.C.00.00.00.
Functionality
Please refer to chapter 11.5.3 “(Remote) Device access via PC-Tool”.
Configuration (CodeLevel: Specialist)
This configuration menu is located under the menu item “Configuration\Communication\USB“.
Configuration Access
via Cfg.-
menu Access
via XML-
Cfg.-File Abbrevia-
tion
(menu) Value range Default values
(after factory reset)
USB device access
(via PC-Tool) rw -- PCTool
Access
On, Off On
11.5.2 Ethernet (only devices with Ethernet option)
„Type 8620 mxCONTROL“ devices with assembled Ethernet option offer remote access and email
notification possibilities.
10/100 Mbit/s Ethernet with TCP/IP
8620
with Ethernet option
Intranet
Firewall
PC
For Access to 8620
via Ethernet
Internet
Mail Server
For email
notification in
Intranet only
(supports SMTP
without authentication)
(with PC-Tool
8620 running )
Mail Server
For email notification in
Intranet and Internet
Firewall
(supports SMTP
without authentication)
DMZ
DHCP Server
Only required if DHCP
was used for automatic
IP address assignment
Figure 12: Remote access and Email notification possibility (with Ethernet option)
