mxCONTROL Type 8620
Page 114
Configuration (CodeLevel: Specialist)
Configuration Access
via Cfg.-
menu Access
via XML-
Cfg.-File Abbreviation
(menu) Value range Default values
(after factory reset or
at start of Cfg-File-
Download)
Module active/not active rw rw Module On/Off Off
Inversion module sense of
action rw rw InvMod Yes / No No
Set point limiter SP Limit
Set point limiter rw rw SP Limit Yes / No No
Lower set point limit (*) rw rw SPLim- Scal- ...SPLim+ Scal- of the assigned
input
Upper set point limit (*) rw rw SPLim+ SPLim- …Scal+ Scal+ of the assigned
input
ASL pump stop rw rw ASL PumpStop Yes / No No
Link to controller Module
CORROSION_DISPLAY r rw linked function --
System switch override rw rw SSOR Yes / No No
Flow switch override rw rw FSOR Yes / No No
Maximum Output Timer rw rw MOT Yes / No No
(*) will be only displayed if the parameter “SP Limit” is set to “Yes”
