mxCONTROL Type 8620
Page 54
Display of current state
Do not change parameters / values, when remote upload or download is active.
The following list shows the displayed symbols for the current remote state.
The symbol for the remote state is located
in the upper left corner of the display, right beside
the Ethernet status symbol.
Configuration
Example Project
System settings
Up/Download
Datalogging
ENTER 6
Symbol Description
Remote user is logged in
Remote Download is active
Remote Upload is active
Remote Control is active
Remote Access is active (reading log files on SD card)
