mxCONTROL Type 8620
Page 15
5.2 Display of the units
Because of the limited display, there is not always sufficient room available for the detailed display of
the unit. Depending on the available positions, 3 or 6 positions are shown in the display; the
equivalents as well as the output during data logging are listed in the following table, arranged by
groups.
Display
max. 3 characters Display
max. 6
characters Display of the unit
selection as well as
data logging unit
Volume units
L L
L Litre
hL hL hL Hectolitre
m3 m3 m3 Cubic metre
Gal Gal US Gal US U.S. liq. Gallon
bbl bbl US bbl US U.S. Barrel
gal gal Im gal Imp Imperial Gallon
ft3 ft3 ft3 Cubic Foot
yd3 yd3 yd3 Cubic Yard
Flow units
L/s
L/s L/s Litre per second
L/m L/min L/min Litres per minute
L/h L/h L/h Litre per hour
m3M m3/min m3/min Cubic metre per minute
m3H m3/h m3/h Cubic metres per hour
G/s Gal/s Gal/s US U.S. liq. Gallons per second
G/m Gal/m Gal/m US U.S. liq. Gallons per minute
G/h Gal/h Gal/h US U.S. liq. Gallons per hour
g/s gal/s gal/s Imp Imperial gallons per second
g/m gal/m gal/m Imp Imperial gallons per minute
g/h gal/h gal/h Imp Imperial gallons per hour
bbS bbl/s bbl/s US U.S. Barrel per second
bbM bbl/m bbl/m US U.S. Barrel per minute
bbH bbl/h bbl/h US U.S. Barrel per hour
f3S ft3/s ft3/s Cubic Feet per second
f3M ft3 /m ft3 /min Cubic Feet per minute
f3H ft3/h ft3/h Cubic Feet per hour
P/s Pul/s Pul/s Pulses per second
P/m Pul/m Pul/m Pulses per minute
Units for chemical analysis
µS µS/cm
µS/cm Microsiemens per centimetre
mS mS/cm mS/cm Millisiemens per centimetre
MPY MPY MPY Mils per year
µMY µMPY µMPY Micromils per year
mV mV mV Millivolt
mgL mg/L mg/L Milligrams per litre
%Sa %Sat %Sat Percent of saturation
pH pH pH pH
Temperature units
°C °C
°C Degree Centigrade
°F °F °F Degree Fahrenheit
°Ra °Rank °Rank Degree Rankine
K K K Kelvin
