mxCONTROL Type 8620
Page 105
Processdata and Data Logging
Display-Presentation Displayed data Abbre-
viation
(menu)
Full
Screen
Trend
chart
Line
Data-
Log.
Notes
Process value System Channel PV1 x x x x
Process value System Channel
(in ppm) PV1 x x x Only if TDS-Display
is configured
Process value Make-Up
Channel PV2 x x x x
Set point SP x x x
Set point vs. Process value
System Channel SP/PV1 x
Module output CMD x x x
Alarm Maximum Output Timer x x is displayed only if
MOT was enabled
and is expired;
Data log in controller
output
Parameter (Code Level: Operator)
Parameter Abbrevia-
tion
(menu) Value range Default values
(after successful download of Cfg-File)
For Make-Up Channel:
Ratio
Kx 1.2 … 9.999 2.0
Offset Offset 0 … 999.9 µS/cm 10 µS/cm
For System Channel:
Switching hysteresis
Hyst 0.1 ... 10.0 % of input
range 1.0 %
Safety output value CMDsafe 0.0 ... 100.00 % 0.0 %
Maximum output timer (MOT)
Maximum output time (*)
+Tm 1 ... 10800 s 10800 s
For TDS-Calibration:
Conductivity value (**)
PV cal 1 ... 99999 (in units of
the assigned process
value input) 1000
TDS value (**) TDS cal 1 ... 99999 ppm 800 ppm
(*) will be only displayed if the parameter “MOT” is configured as “Yes” in the menu „Configuration“
(**) will be only displayed if the parameter “TDS Disp” is configured as “Yes” in the menu „Configuration“
Configuration (CodeLevel: Specialist)
Configuration Access
via
Cfg.-
menu Access
via XML-
Cfg.-File Abbreviation
(menu) Value range Default values
(after factory reset or
at start of Cfg-File-
Download)
Module active/not active rw rw Module On/Off Off
Inversion module sense
of action rw rw InvMod Yes / No No
Pre-bleed and "Biocide
dosing output override" rw rw Prebleed Yes / No No
TDS display rw rw TDS Disp Yes / No No
System switch override rw rw SSOR Yes / No No
Flow switch override rw rw FSOR Yes / No No
Maximum Output Timer rw rw MOT Yes / No No
