mxCONTROL Type 8620
Page 163
21.4.2 PIN Assignment for Low Voltage Level
(Instrumentation Supply)
PIN no.
Signal
Function
Designation in the
configuration menu
37
+24 V DC-Input
57 GND
DC_Power_IN
--
77 PE
38
+24 V DC-Input
58
GND
78
PE
DC_Power_IN
--
39
+24 V DC (Sensor/Transmitter Supply)
59 INPUT
79 GND
Digital/Frequency Input 1
DigIn 1
40
+24 V DC (Sensor/Transmitter Supply)
60
INPUT
80
GND
Digital/Frequency Input 2
DigIn 2
41
+24 V DC (Sensor/Transmitter Supply)
61 INPUT
81 GND
Digital/Frequency Input 3
DigIn 3
42
+24 V DC (Sensor/Transmitter Supply)
62
INPUT
Digital/Frequency Input 4
82
GND
DigIn 4
43
+24 V DC (Sensor/Transmitter Supply)
63
INPUT
Digital Input 5
83 GND
DigIn 5
44
+24 V DC (Sensor/Transmitter Supply)
64
INPUT
Digital Input 6
84
GND
DigIn 6
45
+24 V DC (Sensor/Transmitter Supply)
65
INPUT
Digital Input 7
85 GND
DigIn 7
46
+24 V DC (Sensor/Transmitter Supply)
66
INPUT
Digital Input 8
86
GND
DigIn 8
47
+24 V DC (Sensor/Transmitter Supply)
67 INPUT
4…20mA
Input
1
87 GND
AnalogIn 1
48
+24 V DC (Sensor/Transmitter Supply)
68
INPUT
4…20mA Input 2
88
GND
AnalogIn 2
49
+24 V DC (Sensor/Transmitter Supply)
69 INPUT
4…20mA
Input
3
89 GND
AnalogIn 3
50
+24 V DC (Sensor/Transmitter Supply)
70
INPUT
4…20mA Input 4
90
GND
AnalogIn 4
51
Pt100-current-source
71
INPUT
3-wire Pt100 Input 1
91 GND
AnalogIn 5
52
Pt100-current-source
72
INPUT
3-wire Pt100 Input 2
92
GND
AnalogIn 6
53
+24 V DC
73
OUTPUT
4…20 mA Output 1
93 GND
4…20 mA Output 1
54
+24 V DC
74
OUTPUT
4…20 mA Output 2
94
GND
4…20 mA Output 2
55
+24 V DC
75
PNP-OUTPUT
Transistor Output 1
95 GND
Transistor 1
56
+24 V DC
76
PNP-OUTPUT
Transistor Output 2
96
GND
Transistor 2
