mxCONTROL Type 8620
Page 124
Output Override
The output of this module is influenced at certain states (see figure).
Automatic
Manual
Operation
mode
Manual
Output
Value
0
1
Sensor-/Input
fault
Safety
Output
Value
Module
Output CMD 0
1
System
Switch
0 %
0
1
Flow
Switch
0 %
Output from
Output Limiter
System Switch
override function
can be enabled
or disabled Flow Switch
override function
can be enabled
or disabled
Sensor-/Input
fault of assigned
Flow-Input
Figure 62: Output override (OPEN_PROP).
Processdata and Data Logging
Display-Presentation Displayed data Abbre-
viation
(menu)
Full
Screen
Trend
chart
Line
Data-
Log.
Notes
Flow Process value PV x x x x
Module output CMD x x x
Parameter (CodeLevel: Operator)
Parameter Abbrevia-
tion
(menu) Value range Default values
(after successful download of Cfg-
File)
Lower output limit Lim- 0.0 … Lim- 0.0 %
Upper output limit Lim+ Lim+ … 100.0 % 100.0 %
Safety output value CMDsafe 0.0 … 100.0 % 0.0 %
Configuration (Code Level: Specialist)
Configuration Access
via Cfg.-
menu Access
via XML-
Cfg.-File Abbre-
viation
(menu) Value range Default values
(after factory reset or at
start of Cfg-File-
Download)
Module active/not active rw rw Module On/Off Off
System switch override rw rw FSOR Yes / No No
Flow switch override rw rw SSOR Yes / No No
