Configuration (CodeLevel: Specialist)
Configuration Access
via
Cfg.-
menu Access
via XML-
Cfg.-File Abbre-
viation
(menu) Value range Default values
(after factory reset or at
start of Cfg-File-Download)
Enabling / disabling
input rw rw Input On/Off Off
Special input function rw rw SpecFunc 0: none
1: Square root of PV
0
Process value
scaling: unit rw rw Scal Unit Units of Chem.
Analysis, Volume,
Flow, Temperature,
Misc. No Unit
Process value
scaling: Low scaling
value @ 4 mA rw rw Scal- -99999 … Scal+ -99999
Process value
scaling: High scaling
value @ 20 mA rw rw Scal+ Scal- … 99999 99999
Process value
scaling: Sense of
action rw rw ScalDir Rise / Fall Rise
Filter stage rw rw Filter 0 ... 9 0
Process value alarm
Alarm mode
rw rw Mode Off, Alarm,
Alarm & Warn Alarm & Warn
Low alarm limit (*) rw rw Alarm- -99999 … Alarm+ -99999
High alarm limit (*) rw rw Alarm+ Alarm- … 99999 99999
Alarm hysteresis (*) rw rw AlarmHys 0.1 … 10.0 % of
range (Scal- …
Scal+) 1.0 %
Low warning limit (*) rw rw Warn- Alarm- … Warn+ -99999
High warning limit (*) rw rw Warn+ Warn- … Alarm+ 99999
Warning hysteresis (*) rw rw WarnHys 0.1 … 10.0 % of
range (Scal-…Scal+) 1.0 %
Calibration
Calibration funtionality rw rw CalibFct
No/Yes No
Offset (@4mA) (**) rw rw Offset -99999 … +99999
in [Scal Unit] at 4 mA 0.0
Slope (**) rw rw Slope if ScalDir = Rise:
0 … +99999
if ScalDir = Fall:
-99999 … 0
in [Scal Unit] / [mA] 16 mA / [Scal+ - Scal-]
Apply Default values
to Offset and Slope
(**) -- w Default
values
(*) will be only displayed if the corresponding Alarm Mode is selected
(**) only visible if CalibFct = Yes
