ESG Family Signal Generators Performance Tests
Support Software
Calibration Guide 4-7
You can scroll the results window, vertically and horizontally. You can also click on the
following buttons during the test sequence:
Run Start running the highlighted test when initially starting the testing.
Also used to start testing at the same point where the test was stopped.
Stop Stop the test that is currently running. The test stops after making the
next measurement.
Restart Rerun a test that was running when the testing was stopped. This
restarts the test from the beginning.
Next Test Quit running the current test and give it a Fail status. Then, continue
testing with the next test.
Rerun Restart the testing at the beginning of the first test.
Abort Quit testing. Abort all tests.
To begin a performance test sequence with a new DUT, click File and New Session. This
allows you to reselect the DUT, the equipment list, and the performance test list.
Figure 4-5 The Main Test and Results Window
13.When the software has run all of the selected performance tests, the status bar
indicates that the tests are completed (item 35).
