ESG Family Signal Generators Operation Verification
Verification Procedures
Calibration Guide 2-19
Table 2-5 FM Accuracy
Table 2-6 AM Accuracy
Frequency
(MHz)
Deviation
(kHz)
Limits (kHz)
Lower Measured Upper
500.001 100 kHz 96.48 103.52
750 100 kHz 96.48 103.52
1000 100 kHz 96.48 103.52
Frequency
(MHz)
Depth (%)
Limits (%)
Lower Measured Upper
200 30 27.5 32.5
200 90 84.5 95.5
300 30 27.5 32.5
300 90 84.5 95.5
501 30 27.5 32.5
501 90 84.5 95.5
750 30 27.5 32.5
750 90 84.5 95.5
1000 30 27.5 32.5
1000 90 84.5 95.5
