296
ATmega169V/L
2514A–AVR–08/02
Electrical Characteristics
Absolute Maximum Ratings*
Operating Temperature .................................. -55 °C to +125°C *NOTICE: Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.
Storage Temperature ..................................... -65°C to +150°C
Voltage on any Pin except RESET
with respect to Ground ................................-1.0V to V
CC
+0.5V
Voltage on RESET with respect to Ground......-1.0V to +13.0V
Maximum Operating Voltage ............................................ 4.0V
DC Current per I/O Pin ............................................... 40.0 mA
DC Current V
CC
and GND Pins................................ 200.0 mA
DC Characteristics
T
A
= -40 °C to 85°C, V
CC
= 1.8V to 3.6V (unless otherwise noted)
Symbol Parameter Condition Min. Typ. Max. Units
V
IL
Input Low Voltage Except XTAL1 pin TBD TBD (1) V
V
IL1
Input Low Voltage
XTAL1 pin, External
Clock Selected
TBD TBD (1) V
V
IH
Input High Voltage
Except XTAL1 and
RESET pins
TBD (2) TBD V
V
IH1
Input High Voltage
XTAL1 pin, External
Clock Selected
TBD (2) TBD V
V
IH2
Input High Voltage RESET pin TBD (2) TBD V
V
OL
Output Low Voltage (3) I
OL
= 10 mA, V
CC
= 3V TBD V
V
OH
Output High Voltage (4) I
OH
= -10 mA, V
CC
= 3V TBD V
I
IL
Input Leakage
Current I/O Pin V
CC
= 3.6V, pin low
(absolute value)
TBD µA
I
IH
Input Leakage
Current I/O Pin V
CC
= 3.6V, pin high
(absolute value)
TBD nA
R
RST
Reset Pull-up Resistor TBD TBD k Ω
R
pu
I/O Pin Pull-up Resistor TBD TBD k Ω
I
CC
Power Supply Current
Active 4 MHz, V
CC
= 3V
(ATmega169L)
TBD mA
Idle 4 MHz, V
CC
= 3V
(ATmega169L)
TBD mA
Power-down mode
WDT enabled, V
CC
= 3V TBD TBD µA
WDT disabled, V
CC
= 3V TBD TBD µA
