248
ATmega169V/L
2514A–AVR–08/02
96 EXTCLK (XTAL1) Clock input and Osillators for the main
clock
(Observe-only)
95 OSCCK
94 RCCK
93 OSC32CK
92 PD0.Data Port D
91 PD0.Control
90 PD0.Pullup_Enable
89 PD1.Data
88 PD1.Control
87 PD1.Pullup_Enable
86 PD2.Data
85 PD2.Control
84 PD2.Pullup_Enable
83 PD3.Data
82 PD3.Control
81 PD3.Pullup_Enable
80 PD4.Data
79 PD4.Control
78 PD4.Pullup_Enable
77 PD5.Data
76 PD5.Control
75 PD5.Pullup_Enable
74 PD6.Data
73 PD6.Control
72 PD6.Pullup_Enable
71 PD7.Data
70 PD7.Control
69 PD7.Pullup_Enable
68 PG0.Data Port G
67 PG0.Control
66 PG0.Pullup_Enable
65 PG1.Data
64 PG1.Control
63 PG1.Pullup_Enable
62 PC0.Data Port C
61 PC0.Control
Table 107. ATmega169 Boundary-scan Order (Continued)
Bit Number Signal Name Module
