250
ATmega169V/L
2514A–AVR–08/02
Boundary-scan
Description Language
Files Boundary-scan Description Language (BSDL) files describe Boundary-scan capable
devices in a standard format used by automated test-generation software. The order
and function of bits in the Boundary-scan Data Register are included in this description.
A BSDL file for ATmega169 is available.
24 PA4.Pullup_Enable Port A
23 PA3.Data
22 PA3.Control
21 PA3.Pullup_Enable
20 PA2.Data
19 PA2.Control
18 PA2.Pullup_Enable
17 PA1.Data
16 PA1.Control
15 PA1.Pullup_Enable
14 PA0.Data
13 PA0.Control
12 PA0.Pullup_Enable
11 PF3.Data Port F
10 PF3.Control
9 PF3.Pullup_Enable
8 PF2.Data
7 PF2.Control
6 PF2.Pullup_Enable
5 PF1.Data
4 PF1.Control
3 PF1.Pullup_Enable
2 PF0.Data
1 PF0.Control
0 PF0.Pullup_Enable
Table 107. ATmega169 Boundary-scan Order (Continued)
Bit Number Signal Name Module
