Features
•
High Performance, Low Power AVR
®
8-Bit Microcontroller
•
Advanced RISC Architecture
– 130 Powerful Instructions – Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers
– Fully Static Operation
– Up to 4 MIPS Throughput at 4 MHz
– On-Chip 2-cycle Multiplier
•
Non-volatile Program and Data Memories
– 16K bytes of In-System Self-Programmable Flash
Endurance: 1,000 Write/Erase Cycles
– Optional Boot Code Section with Independent Lock Bits
In-System Programming by On-chip Boot Program
True Read-While-Write Operation
– 512 bytes EEPROM
Endurance: 100,000 Write/Erase Cycles
– 1K byte Internal SRAM
– Programming Lock for Software Security
•
JTAG (IEEE std. 1149.1 compliant) Interface
– Boundary-scan Capabilities According to the JTAG Standard
– Extensive On-chip Debug Support
– Programming of Flash, EEPROM, Fuses, and Lock Bits through the JTAG Interface
•
Peripheral Features
– 4 x 25 Segment LCD Driver
– Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode
– One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture
Mode
– Real Time Counter with Separate Oscillator
– Four PWM Channels
– 8-channel, 10-bit ADC
– Programmable Serial USART
– Master/Slave SPI Serial Interface
– Universal Serial Interface with Start Condition Detector
– Programmable Watchdog Timer with Separate On-chip Oscillator
– On-chip Analog Comparator
– Interrupt and Wake-up on Pin Change
•
Special Microcontroller Features
– Power-on Reset and Programmable Brown-out Detection
– Internal Calibrated Oscillator
– External and Internal Interrupt Sources
– Five Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, and
Standby
•
I/O and Packages
– 53 Programmable I/O Lines and 1 Input Line
– 64-lead TQFP
•
Operating Voltage:
– 1.8 - 3.6V for ATmega169V
– 2.7 - 3.6V for ATmega169L
•
Temperature Range:
– -10
°
C to 50
°
C
•
Speed Grade:
– 0 - 1 MHz for ATmega169V
– 0 - 4 MHz for ATmega169L
•
Ultra-Low Power Consumption
– Active Mode:
1 MHz, 1.8V: 300
µA
32 kHz, 1.8V: 20
µA (including Oscillator)
32 kHz, 1.8V: TBD (including Oscillator and LCD)
– Power-down Mode:
0.5
µA at 1.8V
8-bit
Microcontroller
with 16K Bytes
In-System
Programmable
Flash
ATmega169V
ATmega169L
Advance
Information
Rev. 2514A–AVR–08/02
