Page 147

147

ATmega169V/L

2514A–AVR–08/02

• Bit 4 – MSTR: Master/Slave Select

This bit selects Master SPI mode when written to one, and Slave SPI mode when written
logic zero. If SS is configured as an input and is driven low while MSTR is set, MSTR will
be cleared, and SPIF in SPSR will become set. The user will then have to set MSTR to
re-enable SPI Master mode.

• Bit 3 – CPOL: Clock Polarity

When this bit is written to one, SCK is high when idle. When CPOL is written to zero,
SCK is low when idle. Refer to Figure 66 and Figure 67 for an example. The CPOL func-
tionality is summarized below:

• Bit 2 – CPHA: Clock Phase

The settings of the Clock Phase bit (CPHA) determine if data is sampled on the leading
(first) or trailing (last) edge of SCK. Refer to Figure 66 and Figure 67 for an example.
The CPOL functionality is summarized below:

• Bits 1, 0 – SPR1, SPR0: SPI Clock Rate Select 1 and 0

These two bits control the SCK rate of the device configured as a Master. SPR1 and
SPR0 have no effect on the Slave. The relationship between SCK and the Oscillator
Clock frequency f

osc

is shown in the following table:

Table 67. CPOL Functionality

CPOL

Leading Edge

Trailing Edge

Rising

Falling

Rising

Table 68. CPHA Functionality

CPHA

Leading Edge

Trailing Edge

Sample

Setup

Sample

Table 69. Relationship Between SCK and the Oscillator Frequency

SPI2X

SPR1

SPR0

SCK Frequency

osc

128

osc
