Power Supply Operation
TM-XDOP-01XN 3–9
Set Power
The POWER SETPOINT menu option lets you select the power output limit,
measured in watts. The following table shows how to access and work with the
Power Setpoint option. The power setpoint is normally at the maximum rating of
the power supply, in the factory default configuration and does not need to be re-
set for typical use.
Turn Output On or Off
Use the OUT ON/OFF toggle key to enable or disable the power supply’s output.
When the output is disabled, the voltage and current at the output are zero
regardless of the setpoints.
When the output is on and you press OUT ON/OFF, OUTPUT OFF is
momentarily displayed. Then the readback is 0000V 0000A to indicate that
output is zero, and the OUT OFF annunciator illuminates. This is also known as
Standby mode.
When you press OUT ON/OFF again, the OUT ON annunciator illuminates and
the power supply resumes normal operation, with the display showing a readback
of the output.
Step # Do This You Will See
1 ERROR MSGS
2 Press 8 times. POWER SETPOINT
3 SET ##### W
4 Use the numeric keypad or
arrow keys to enter the value,
which must be 0–103% of the
unit’s rated power.
5 This saves the value and enables the
new power setpoint.
MENU
ENTER
ENTER
