Current Sharing

5–6

TM-XDOP-01XN

Errors

The master annuciator will flash if it does not detect any slave units on the
network.

The slave annunciator will flash if it does not detect a master on the network.
Check the cable and the master configuration.

A master or slave will be disabled from current sharing (set to "No share") if:

there is more than one master connected to the CANbus, (Error +1911)

there are more than 4 slaves, (Error +1922), or

the model does not match that of the master, (Error +1922).

In each of these cases, the current share mode will be set to "No share".

If a unit becomes disconnected due to a failure in communications, the master will
queue error +1912, "Current Share Slave Lost" and the slave will
queue error +1921, "Current Share Master Lost." The slave's
output will be disabled, and the slave annunciator will flash.

See Table D-13, “Current Share Error Codes” on page D–9 for the list of error
codes and messages.

CANbus Specifications

Max cable length

40m

Bus speed

700 kbits/sec

Termination

120 ohm, 1/4 Watt

Connections

parallel male DB9 to female DB9 cable
