S

C

PI C

o

mmand S

u

mmary

TM-XDOP-01XN

C

–27

Table C-11 Protection Commands

Function

SCPI Command

Description

Query

Set Over
Temperature
Response

[:]SENSe[]:TEMPerature:PROTection:LAT

Ch

Select if output is latched off or
auto recovers in the case of an
over temperature condition

Yes

Query Over
Temperature
Protection Tripped

[:]SENSe[]:TEMPerature:PROTection:TRI

Pped?

Query temperature protection
tripped

N/A

Set AC Fail
Response

[:]SENSe[]:VOLTage:AC:PROTection:LATC

h

Select if output is latched off or
auto recovers in the case of an AC
Fail

Yes

Query AC Fail
Protection Tripped

[:]SENSe[]:VOLTage:AC:PROTection:TRIP

ped?

Query AC protection circuit
tripped

N/A

Table C-12 User Lines

Function

SCPI Command

Description

Query

Select polarity of
Auxiliary Lines

[:]OUTPut[]:AUXiliary:POLarity

{HIGH|LOW}

Configure the polarity of the
auxiliary line

Yes

Select Source of
Auxiliary Line State

[:]OUTPut[]:AUXiliary:SOURce

Configure the auxiliary line

Yes

Query state of
Auxiliary Line

[:]OUTPut[]:AUXiliary:STATe?

Query the state of the auxiliary
line

N/A
