Xantrex Technology XDC 20-600 - Manual (Page 237)

S
C
PI C
o
mmand S
u
mmary
TM-XDOP-01XN
C
–13
Table C-3 Commands for Output Control
Function SCPI Command Description Query
Set (Immediate)
Current Setpoint [[:]SOURce][]:CURRent[:LEVel][:IMMediat
e][:AMPLitude] {|MAXimum|MINimum}
Change current setpoint Yes
Set Triggered
Current Setpoint [[:]SOURce][]:CURRent[:LEVel]:TRIGgered
[:AMPLitude] {|MAXimum|MINimum|DEFault}
Change triggered current setpoint Yes
Set (Immediate)
Power Setpoint [[:]SOURce][]:POWer[:LEVel][:IMMediate]
[:AMPLitude] {|MAXimum|MINimum}
Change power setpoint Yes
Set Triggered
Power Setpoint [[:]SOURce][]:POWer[:LEVel]:TRIGgered[:
AMPLitude] {|MAXimum|MINimum|DEFault}
Change triggered power setpoint Yes
Set (Immediate)
Voltage Setpoint [[:]SOURce][]:VOLTage[:LEVel][:IMMediat
e][:AMPLitude] {|MAXimum|MINimum}
Change voltage setpoint Yes
Set Triggered
Voltage Setpoint [[:]SOURce][]:VOLTage[:LEVel]:TRIGgered
[:AMPLitude] {|MAXimum|MINimum|DEFault}
Change triggered voltage setpoint Yes
Set Voltage Slew
Rate Voltage [[:]SOURce][]:VOLTage:SLEW:STEP{
te-voltage>|MAXimum|MINimum|DEFault}
Sets the voltage slew rate voltage
change for the programmed time
interval Yes
Set Voltage Slew
Rate Interval [[:]SOURce][]:VOLTage:SLEW:INTerval{
ewrate-interval>|MAXimum|MINimum|DEFault}
Sets the voltage slew rate time
interval for the programmed
voltage change Yes
Set Over Current
Protection Level [[:]SOURce][]:CURRent:PROTection[:OVER]
[:LEVel] {|MAXimum|MINimum}
Set the over current protection
level Yes
Set Over Current
Protection
Shutdown State [[:]SOURce][]:CURRent:PROTection[:OVER]
:STATe
Select over current protection to
shutdown (ON) or set alarm
(OFF) Yes
Query Over
Current Protection
Tripped [[:]SOURce][]:CURRent:PROTection[:OVER]
:TRIPped?
Query if over current protection
mechanism has tripped N/A
Set Under Current
Protection Level [[:]SOURce][]:CURRent:PROTection:UNDer[
:LEVel] {|MAXimum|MINimum}
Set under current protection level Yes
Set Under Current
Protection
Shutdown State [[:]SOURce][]:CURRent:PROTection:UNDer:
STATe
Select under current protection to
shutdown (ON) or set alarm
(OFF) Yes
TM-XDOP-01XN.book Page 13 Monday, July 17, 2006 11:19 AM
