Front Panel
TM-XDOP-01XN 1–3
Front Panel
Figure 1-1 Front Panel (6000 Watt)
Table 1-1 Item Descriptions for Figure 1-1
Item Description
1 Rack mount brackets
2 Handles
3 On/Off Switch
4 Air intake vents
5 Front panel display (vacuum fluorescent display). See Figure 1-4
for details.
6 Voltage knob
7 Current knob
8 Keypad. (See Figure 1-3 for details.)
1
2
3 4 5 6 7 8 1
2
