Xantrex Technology XDC 20-600 - Manual (Page 244)

SC
PI Co
mmand Re
fe
ren
ce
C–20
TM-XDOP-01XN
Table C-10 Status Commands
Function SCPI Command Description Query
Power On Status
Clear (*PSC) [:]STATus[]:POSClear Controls the automatic power-on
clearing of the Service Request
Enable Register, Standard Event
Status Enable Register, Parallel
Poll Enable Register and other
event enable registers Yes
Query Operation
Status Condition
Register [:]STATus[]:OPERation:CONDition? See Table 4-9 on page 4–46. N/A
Set Operation Status
Enable Register [:]STATus[]:OPERation:ENABle
enable>
See Table 4-9 on page 4–46. Yes
Query Operation
Status Event
Register [:]STATus[]:OPERation[:EVENt]? See Table 4-9 on page 4–46. N/A
Set Operation Status
Negative Transition
Register [:]STATus[]:OPERation:NTRansition See Table 4-9 on page 4–46. Yes
Set Operation Status
Positive Transition
Register [:]STATus[]:OPERation:PTRansition See Table 4-9 on page 4–46. Yes
Query Operation
Status Current
Sharing Condition
Register [:]STATus[]:OPERation:CSHare:CONDitio
n?
See Table 4-14 on page 4–50. N/A
Set Operation Status
Current Sharing
Enable Register [:]STATus[]:OPERation:CSHare:ENABle See Table 4-14 on page 4–50. Yes
Query Operation
Status Current
Sharing Event
Register [:]STATus[]:OPERation:CSHare[:EVENt]? See Table 4-14 on page 4–50. N/A
