Protocol Specifications

TM-XDOP-01XN

E–3

Protocol Specifications

Multiline Control Functions

IEEE 488.2 (Section 5) requires specific Device Interface Functions.

Interface Functions

IEEE 488.1 (Section 2).

Table E-1 Multiline Control Functions

Function

Mnemonic

Description

Functions Subset

Source
Handshake

SH1

Complete capability

SIDS, SGNS, SDYS, STRS, SWNS, SIWS

Acceptor
Handshake

AH1

Complete capability

AIDS, ANRS, ACRS, ACDS, AWNS

Talker

T6 Includes

serial

poll

TIDS,

TADS, TACS, SPAS, SPIS, SPMS, TPIS,

TPAS

Listener

L4

LIDS, LADS, LACS, LPIS, LPAS

Table E-2 Interface Functions

Function

Mnemonic

Description

Functions Subset

Device Clear

DC1

Complete capability

DCIS, DCAS

Device Trigger

DT1

Complete capability

DTIS, DTAS

Drivers

E2

Tri state drivers where selectable

Parallel Poll

PP1

Parallel Poll

Remote/Local

RL1

Complete capability

LOCS, LWLS, REMS, RWLS

Service
Request

SR1

Complete capability

NPRS, SQRS, APRS

Controller

C0

Device does not act as a controller
