Remote Operation

4–20

TM-XDOP-01XN

Configuration

Configure the power supply’s GPIB address and power-on service request setting.
The defaults are GPIB address 2 and power-on service request off.

Front panel

First set the GPIB parameters:

Next, select GPIB as the remote control interface:

Step # Do This

You Will See

1

ERROR MSGS

2

5 times

REMOTE CONFIG

3

RS-232 Cfg

2 times

GPIB Cfg

4

GPIB Addr ##

5

Select an address from 1-30

GPIB Addr 2

6

PON SRQ? Y

7

or

Select whether power-on service
request is to be sent.

Options are
Y (Yes) or
N (No)

8

Settings are saved.

MENU

ENTER

ENTER

ENTER

ENTER

Step # Do This

You Will See

1

ERROR MSGS

2

4 times

REMOTE SELECT

3

RS-232

4

or

Select GPIB.

GPIB

5

GPIB setting is saved.

MENU

ENTER

ENTER
