Operation

3–46

TM-XDOP-01XN

To set the voltage limits:

Step # Do This

You Will See

1

ERROR MSGS

2

until you see the “SETPT LIMIT”

option

SETPT LIMIT

3

Voltage Limit

4

High 0V

5

Use the Voltage knob, arrow keys, or
numeric keypad to enter a value. The value
must be within 0V to 103% of the unit’s
rated voltage, and must be higher than the
voltage setpoint.

High #####V

6

Low 0V
The Maximum setting is
saved and the Minimum
setting appears.

7

Use the Voltage knob, arrow keys, or
numeric keypad to enter a value. The value
must be within 0V to 103% of the unit’s
rated voltage and must be lower than the
voltage setpoint.

Low #####V

8

The setting is saved and
the display returns to its
default operating mode.

MENU

ENTER

ENTER

ENTER

ENTER
