Remote Operation

4–8

TM-XDOP-01XN

Configure Analog Control

You may configure the analog programming lines to work in either a 0 to 5V
range or a 0 to10V range. You may also select whether the voltage, current or both
are controlled with the programming lines. If you select only voltage or only
current, the other will be controlled via the front panel.

Front Panel

First, configure the analog programming lines.

Next select analog programming as the remote control interface.

Your options are

Analog V & I - voltage and current programmed via the analog interface

Analog V - voltage programmed via the analog interface; current set via front
panel

Analog I - current programmed via the analog interface; voltage set via front
panel

Step # Do This

You Will See

1

ERROR MSGS

2

5 times

a

REMOTE CONFIG

3

RS-232 Cfg

4

Analog Cfg

5

Input 0-5V

6

or

Select the input range.

0-5V or
0-10V

7

Setting is saved and menu is exited.

a. You can also press MENU 5 times.

MENU

ENTER

ENTER

ENTER
