GPIB Operation

TM-XDOP-01XN

4–21

SCPI

To set up GPIB control parameters:

SYST:COMM:GPIB:ADDR

where

the GPIB address may be in the range 1 to 30.

To configure the unit to generate a power-on service request:

SYST:COMM:GPIB:PONS {ON | OFF}

To select GPIB as the remote control source:

SYST:REM:SOUR GPIB

Using GPIB

Sending a GPIB command should put the power supply in remote mode with the
RMT annunciator lit.

Refer to the manual for your GPIB interface card. Commands to change remote
and local mode will be specific to that card.

Press the LCL/RMT button to return to local mode, except if the power supply is
in LLO (local lockout) state.
