Chapter 5 Configuring IPmux-11 for a Typical Application Installation and Operation Manual
5-2 Configuring IPmux-11 Units IPmux-11 Ver. 2.00
Table 5-1. Configuration Summary
Device E1 Parameters IP Parameters Bundle
Parameters Bundle Connection
IPmux-11 (A) • Transmit clock source:
adaptive
• Line type: Framed G.704
CRC-4 enabled
• CAS: disabled
Host IP address:
192.168.10.2 Bundle 1
Timeslots in
bundle: 1–10
Bundle 1 of IPmux-11 (B)
IPmux-11 (B) • Transmit clock source:
Loopback
• Line type: Framed G.704
CRC-4 enabled
• CAS: disabled
Host IP address:
192.168.10.1 Bundle 1
Timeslots in
bundle: 1–10
Bundle 1 of IPmux-11 (A)
5.2 Configuring IPmux-11 Units
This section explains how to configure IPmux-11 units. The configuration
procedure is similar for both units, except for defining different host IP addresses,
different clocking modes and different destination IP address for the bundle
connection. Refer to
Chapter 3 for explanation of how to select management
options and save the changes.
Configuring the IP Parameters
To configure the host IP parameters:
• Display the Host IP menu (Configuration > System > Host IP), and configure
the IP address and mask of the host:
1. Disable the DHCP mechanism
2. Save the changes
3. Set the IPmux-11 (A) host IP address – 192.168.10.2
4. Set the IPmux-11 (B) host IP address – 192.168.10.1
5. Save the changes.
Configuration>System>Host IP
1. IP address ... (192.168.10.2)
2. IP mask ... (255.255.255.0)
3. Default gateway ... (0.0.0.0)
4. DHCP (Disable)
5. DHCP Status >
>
Please select item <1 to 5>
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 5-2. Configuring Host IP Parameters for IPmux-11 (A)
