Installation and Operation Manual Chapter 4 Configuration
IPmux-11 Ver. 2.00 Additional Tasks 4-27
4.4 Additional Tasks
Displaying the IPmux-11 Inventory
The IPmux-11 inventory displays information on current software and hardware
revisions of the unit. It also provides the IPmux-11 interface description.
To display the IPmux-11 inventory:
• From the Main menu, select Inventory.
Inventory
SOFTWARE
Boot version (1.00 )
Application version (2.00D1 01/02/2005 16:47:18)
Backup version (2.00D1 01/02/2005 16:47:18)
HARDWARE
Version (1.00 )
MAC address (0020D2213FE7)
... (N)
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-26. Inventory Screen (Page 1)
Inventory
... (P)
INTERFACE
TDM1 (E1 over UTP)
ETH1/Net (ETHERNET over Multimode LC)
ETH2/User1 (ETHERNET over UTP)
ETH3/User2 (ETHERNET over UTP)
External clock (UTP)
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-27. Inventory Screen (Page 2)
Setting the Date and Time
You can set the date and time for the IPmux-11 internal real-time clock.
To set date and time:
1. From the System menu (
Figure 4-1 ), select Date/time.
The Date/Time menu appears (see Figure 4-28 ).
