Installation and Operation Manual Chapter 4 Configuration
IPmux-11 Ver. 2.00 Additional Tasks 4-29
Monitoring>Status>Diagnostics loopback
Channel ID (1) Loopback state: > (Disable)
>
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-30. Diagnostics loopback Screen
Displaying the TDM Physical Layer Information
You can view the status of the TDM layer at the physical level.
To display the TDM physical layer information:
• From the Status menu, select TDM Physical layer.
Monitoring>Status>TDM physical layer (T1)
Channel ID (1) Loopback state: > (Disable)
>
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-31. TDM Physical Layer Screen
Displaying the Ethernet Physical Layer Information
You can view the status of the Ethernet connections at the physical level.
To display the Ethernet physical layer information:
1. From the Status menu, select ETH Physical layer.
The Physical Layer screen is displayed (see Figure 4-32 ).
2. From the Physical Layer screen, type F to toggle between the available
Ethernet interfaces.
