IPmux-11 Ver. 2.00 Overview 1-1
Chapter 1
Introduction
1.1 Overview
IPmux-11 offers a solution for extending traditional E1/T1 transparently over
packet switched networks (PSNs) such as IP, Ethernet, and MPLS networks. The
device converts the data stream coming from its TDM ports into configurable-sized
packets that are extended over the Fast Ethernet network port, and vice versa.
IPmux-11 offers end-to-end synchronization for voice/leased line applications.
IPmux-11 also features two Fast Ethernet user ports for data (Ethernet) connectivity
to the IP/Ethernet network. Management is performed locally by a terminal, or
remotely via Web, Telnet, or SNMP.
Versions
IPmux-11 is available with different hardware configurations. The following
versions are available:
• TDM interface options:
E1 for balanced E1 interface
E1CX for unbalanced E1 interface (via supplied adapter cable)
T1 for T1 interface
• Network Ethernet interface options:
UTP for 10/100BaseT interface, RJ-45 connector
MM13LC for multimode 1310 nm - 100BaseFx interface, LC connector
SM13LC for single mode 1310 nm - 100BaseFx interface, LC connector
• User Ethernet interface options:
UTP for 10/100BaseT user interface, RJ-45 connector
