Installation and Operation Manual Chapter 4 Configuration
IPmux-11 Ver. 2.00 Configuring IPmux-11 for Operation 4-11
To select the baud rate:
1. From the System menu (
Figure 4-1 ), select Control port.
The Control Port menu is displayed (see Figure 4-11 ).
2. From the Control Port menu, select Baud rate, and configure baud rate of the
IPmux-11 terminal control port to the desired value (9600, 19200, 38400,
57600 or 11520 bps).
Configuration>System>Control port
Data bits (8)
Parity > (None)
Stop bits (1)
Flow control > (None)
1. Baud rate (bps) > (115200)
>
Please select item <1 to 1>
ESC-prev.menu; !-main menu; &-exit 1 Mngr/s
Figure 4-11. Control Port Menu
4.3 Configuring IPmux-11 for Operation
Configuring the System Clock
You can configure the parameters of the IPmux-11 system clock, including the
master clock and fall back clock. If the clock is adaptive or Rx clock then you can
also configure the clock source.
If the configured fallback clock source fails, the internal timing is used as the fallback
clock source instead.
To configure the system clock:
1. From the System menu (
Figure 4-1 ), select System clock.
The System clock menu appears (See Figure 4-12).
2. From the System clock menu, configure the following:
Master clock (Master clock type):
Internal
Adaptive
Rx clock
Master source (Master clock source):
Channel 1
Channel 2
Channel 3
Note
